com.github.ivbaranov:rxbluetooth

RxBluetooth

Android reactive bluetooth library. Basically, RxBluetooth is just wrapper around android BluetoothAdapter, so first of all the Bluetooth developer guide should be read.

RxBluetooth is in early-stage. There is a lot of missing stuff. Feel free to contribute.

Full documentation

• Wiki
• Javadoc

Usage

1. Declare permissions:

   <uses-permission android:name="android.permission.BLUETOOTH" />
   <uses-permission android:name="android.permission.BLUETOOTH_ADMIN" />
   // If you intend to run on devices with android 6.0+ you also need to declare:
   <uses-permission android:name="android.permission.ACCESS_COARSE_LOCATION" />
   <uses-permission android:name="android.permission.ACCESS_FINE_LOCATION" />


2. Create RxBluetooth instance.

   RxBluetooth rxBluetooth = new RxBluetooth(this); // `this` is a context


3. For android 6.0+ you need location permision.

   if (ContextCompat.checkSelfPermission(this, android.Manifest.permission.ACCESS_FINE_LOCATION) != PackageManager.PERMISSION_GRANTED) {
        ActivityCompat.requestPermissions(this, new String[]{android.Manifest.permission.ACCESS_FINE_LOCATION}, PERMISSION_REQUEST_COARSE_LOCATION);
   }
   // And catch the result like this:
    @Override
    public void onRequestPermissionsResult(int requestCode, @NonNull String[] permissions, @NonNull int[] grantResults) {
        super.onRequestPermissionsResult(requestCode, permissions, grantResults);
        if (requestCode == PERMISSION_REQUEST_COARSE_LOCATION) {
            for (String permission : permissions) {
                if (android.Manifest.permission.ACCESS_FINE_LOCATION.equals(permission)) {
                    // Do stuff if permission granted
                }
            }
        }
    }


4. Check that bluetooth is available and enabled:

   // check if bluetooth is supported on your hardware
   if  (!rxBluetooth.isBluetoothAvailable()) {
      // handle the lack of bluetooth support
   } else {
      // check if bluetooth is currently enabled and ready for use
      if (!rxBluetooth.isBluetoothEnabled()) {
         // to enable bluetooth via startActivityForResult()
         rxBluetooth.enableBluetooth(this, REQUEST_ENABLE_BT);
      } else {
         // you are ready
      }
   }


5. Have fun.

6. Make sure you are unsubscribing and stopping discovery in OnDestroy():

   if (rxBluetooth != null) {
         rxBluetooth.cancelDiscovery();
       }
   unsubscribe(rxBluetoothSubscription);


Observing devices

rxBluetooth.observeDevices()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .subscribe(new Action1<BluetoothDevice>() {
        @Override public void call(BluetoothDevice bluetoothDevice) {
          //
        }
      });

Create connection to device

// Use 00001101-0000-1000-8000-00805F9B34FB for SPP service
// (ex. Arduino) or use your own generated UUID.
UUID uuid = UUID.fromString("xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx");

rxBluetooth.observeConnectDevice(bluetoothDevice, uuid)
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.io())
      .subscribe(new Action1<BluetoothSocket>() {
        @Override public void call(BluetoothSocket socket) {
          // Connected to the device, do anything with the socket
        }
      }, new Action1<Throwable>() {
       @Override public void call(Throwable throwable) {
         // Error occured
       }
     });

Observing discovery state

To observe just ACTION_DISCOVERY_STARTED:

rxBluetooth.observeDiscovery()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .filter(Action.isEqualTo(BluetoothAdapter.ACTION_DISCOVERY_STARTED))
      .subscribe(new Action1<String>() {
        @Override public void call(String action) {
          //
        }
      });

To observe both ACTION_DISCOVERY_STARTED and ACTION_DISCOVERY_FINISHED:

rxBluetooth.observeDiscovery()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .filter(Action.isEqualTo(BluetoothAdapter.ACTION_DISCOVERY_STARTED, BluetoothAdapter.ACTION_DISCOVERY_FINISHED))
      .subscribe(new Action1<String>() {
        @Override public void call(String action) {
          //
        }
      });

Observing bluetooth state

rxBluetooth.observeBluetoothState()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .filter(Action.isEqualTo(BluetoothAdapter.STATE_ON))
      .subscribe(new Action1<Integer>() {
        @Override public void call(Integer integer) {
          //
        }
      });

You can observe single or multiple states:

BluetoothAdapter.STATE_OFF
BluetoothAdapter.STATE_TURNING_ON
BluetoothAdapter.STATE_ON
BluetoothAdapter.STATE_TURNING_OFF

Observing scan mode

rxBluetooth.observeScanMode()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .filter(Action.isEqualTo(BluetoothAdapter.SCAN_MODE_CONNECTABLE_DISCOVERABLE))
      .subscribe(new Action1<Integer>() {
        @Override public void call(Integer integer) {
          //
        }
      });

You can observe single or multiple scan modes:

BluetoothAdapter.SCAN_MODE_NONE
BluetoothAdapter.SCAN_MODE_CONNECTABLE
BluetoothAdapter.SCAN_MODE_CONNECTABLE_DISCOVERABLE

Getting the profile proxy object

rxBluetooth.observeBluetoothProfile(myProfile)
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .subscribe(new Action1<ServiceEvent>() {
        @Override public void call(ServiceEvent serviceEvent) {
          switch (serviceEvent.getState()) {
           case CONNECTED:
                BluetoothProfile bluetoothProfile = serviceEvent.getBluetoothProfile();
                List<BluetoothDevice> devices = bluetoothProfile.getConnectedDevices();
                for ( final BluetoothDevice dev : devices ) {
                  //..
                }
                break;
           case DISCONNECTED:
                //serviceEvent.getBluetoothProfile() returns null
                break;
            }
          }
        });

myProfile can be one of BluetoothProfile.HEALTH, BluetoothProfile.HEADSET, BluetoothProfile.A2DP, BluetoothProfile.GATT or BluetoothProfile.GATT_SERVER

Clients should close profile proxy when they are no longer using the proxy obtained from observeBluetoothProfile:

rxBluetooth.closeProfileProxy(int profile, BluetoothProfile proxy);

Observing device state

To observe the current device state, you can receive the ConnectionStateEvent which provides the state, previous state, and BluetoothDevice.

rxBluetooth.observeConnectionState()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .subscribe(new Action1<ConnectionStateEvent>() {
        @Override public void call(ConnectionStateEvent event) {
          switch (event.getState()) {
            case BluetoothAdapter.STATE_DISCONNECTED:
                // device disconnected
                break;
            case BluetoothAdapter.STATE_CONNECTING:
                // device connecting
                break;
            case BluetoothAdapter.STATE_CONNECTED:
                // device connected
                break;
            case BluetoothAdapter.STATE_DISCONNECTING:
                // device disconnecting
                break;
          }
        }
      });

Possible states are:

BluetoothAdapter.STATE_DISCONNECTED
BluetoothAdapter.STATE_CONNECTING
BluetoothAdapter.STATE_CONNECTED
BluetoothAdapter.STATE_DISCONNECTING

Observing device bond state

To observe the bond state of devices, you can receive the BondStateEvent which provides the state, previous state, and BluetoothDevice.

rxBluetooth.observeBondState()
      .observeOn(AndroidSchedulers.mainThread())
      .subscribeOn(Schedulers.computation())
      .subscribe(new Action1<BondStateEvent>() {
        @Override public void call(BondStateEvent event) {
          switch (event.getState()) {
            case BluetoothDevice.BOND_NONE:
                // device unbonded
                break;
            case BluetoothDevice.BOND_BONDING:
                // device bonding
                break;
            case BluetoothDevice.BOND_BONDED:
                // device bonded
                break;
          }
        }
      });

Possible states are:

BluetoothDevice.BOND_NONE
BluetoothDevice.BOND_BONDING
BluetoothDevice.BOND_BONDED

Read and Write with BluetoothSocket

After creating a connection to the device, you can use BluetoothConnection class to read and write with its socket.

Read:

BluetoothConnection bluetoothConnection = new BluetoothConnection(bluetoothSocket);

// Observe every byte received
bluetoothConnection.observeByteStream()
    .observeOn(AndroidSchedulers.mainThread())
    .subscribeOn(Schedulers.io())
    .subscribe(new Action1<Byte>() {
      @Override public void call(Byte aByte) {
        // This will be called every single byte received
      }
    }, new Action1<Throwable>() {
      @Override public void call(Throwable throwable) {
        // Error occured
      }
    });

// Or just observe string
bluetoothConnection.observeStringStream()
    .observeOn(AndroidSchedulers.mainThread())
    .subscribeOn(Schedulers.io())
    .subscribe(new Action1<String>() {
      @Override public void call(String string) {
        // This will be called every string received
      }
    }, new Action1<Throwable>() {
      @Override public void call(Throwable throwable) {
        // Error occured
      }
    });

Write:

bluetoothConnection.send("Hello"); // String
bluetoothConnection.send("There".getBytes()); // Array of bytes

Observe ACL actions

rxBluetooth.observeAclEvent() //
            .observeOn(AndroidSchedulers.mainThread())
            .subscribeOn(Schedulers.computation())
            .subscribe(new Action1<AclEvent>() {
              @Override public void call(AclEvent aclEvent) {
                switch (aclEvent.getAction()) {
                  case BluetoothDevice.ACTION_ACL_CONNECTED:
                    //...
                    break;
                  case BluetoothDevice.ACTION_ACL_DISCONNECT_REQUESTED:
                    //...
                    break;
                  case BluetoothDevice.ACTION_ACL_DISCONNECTED:
                    //...
                    break;
                }
              }
            });

Download

compile 'com.github.ivbaranov:rxbluetooth:0.1.6'

Snapshots of the development version are available in Sonatype's snapshots repository.

Contributing

Make sure you use SquareAndroid code style. (https://github.com/square/java-code-styles)

Create a branch for each feature.
