@engr-lukman/vue-secure-pin

Vue Secure PIN

A secure PIN input component for Vue.js applications with a virtual keyboard and PIN masking, specifically designed for financial applications.

Demo

Check out the interactive Storybook demo to see the component in action.

Features

• Secure PIN Entry: Automatically masks PIN input for privacy
• Virtual Keyboard: Prevents keylogging and enhances security
• Shuffle Option: Randomizes keypad numbers for added security
• TypeScript Support: Full type definitions and type safety
• Customizable: Easy to style and adapt to your application's design
• Simple API: Straightforward props and events

Requirements

• Vue.js 3.0 or higher
• Node.js 20.0 (LTS) or higher
• TypeScript 4.5+ (for TypeScript users)

Installation

# Using npm
npm install @engr-lukman/vue-secure-pin

# Using yarn
yarn add @engr-lukman/vue-secure-pin

# Using pnpm
pnpm add @engr-lukman/vue-secure-pin

Usage

Register as a Plugin (Global)

// main.ts
import { createApp } from "vue";
import App from "./App.vue";
import SecurePinPlugin from "@engr-lukman/vue-secure-pin";

const app = createApp(App);
app.use(SecurePinPlugin);
app.mount("#app");

Import Component Directly

// In your Vue component with script setup
import { SecurePin } from "@engr-lukman/vue-secure-pin";

// For Vue 3 script setup syntax
// No further registration needed

TypeScript Usage Example

<template>
  <div>
    <SecurePin
      :max-length="5"
      :is-error="hasError"
      :error-message="errorMessage"
      :is-enable-shuffle="true"
      @callback-event="handlePinChange"
    />
  </div>
</template>

<script setup lang="ts">
import { ref } from 'vue';
import { SecurePin } from "@engr-lukman/vue-secure-pin";
import type { PinEventPayload } from "@engr-lukman/vue-secure-pin";

const hasError = ref<boolean>(false);
const errorMessage = ref<string>("");

const handlePinChange = (payload: PinEventPayload): void => {
  // Get the actual and masked PIN values
  const { pin, pinMasked } = payload;

  // Example validation
  if (pin === "12345") {
    hasError.value = false;
  } else if (pin.length === 5) {
    hasError.value = true;
    errorMessage.value = "Invalid PIN. Please try again.";
  }
};
</script>

// For Vue 3 Options API or Vue 2
export default {
  components: {
    SecurePin
  }
}

Basic Example with Form Validation

<template>
  <div class="form-group">
    <label>{{ $t("pin.label") }}</label>
    <secure-pin
      :max-length="5"
      :is-error="v$.pinMasked.$error"
      :error-message="v$.pinMasked.$errors[0]?.$message"
      :placeholder="$t('pin.placeholder')"
      :is-enable-shuffle="true"
      :show-keyboard="true"
      :title="$t('keyboard.title')"
      :clear-label="$t('keyboard.clear')"
      @callback-event="onPinHandler"
    />
  </div>
</template>

<script setup lang="ts">
import useVuelidate from "@vuelidate/core";
import { helpers, required } from "@vuelidate/validators";
import { reactive } from "vue";
import { useI18n } from "vue-i18n";

// Import the SecurePin component and its types
import { SecurePin } from "@engr-lukman/vue-secure-pin";
import type { PinEventPayload } from "@engr-lukman/vue-secure-pin";

const { t } = useI18n();

// Define validation rules
const rules = {
  pin: { required: helpers.withMessage(t("pin.required"), required) },
  pinMasked: {
    required: helpers.withMessage(t("pin.required"), required),
    policy: helpers.withMessage(
      t("pin.validation"),
      helpers.regex(/^[\d*]{4,5}$/)
    ),
  },
};

// Type-safe reactive form payload
interface PinPayload {
  pin: string;
  pinMasked: string;
}

const payload = reactive<PinPayload>({
  pin: "",
  pinMasked: "",
});

const v$ = useVuelidate(rules, payload, { $autoDirty: true });

// Type-safe callback handler
const onPinHandler = (event: PinEventPayload): void => {
  const { pin, pinMasked } = event;

  console.log("Actual PIN:", pin); // Shows "12345" (the actual PIN)
  console.log("Masked PIN:", pinMasked); // Shows "*****"

  payload.pin = pin;
  payload.pinMasked = pinMasked;
};
</script>

Component Architecture

The Secure PIN component consists of:

• SecurePin.vue: Main component that provides the input field and keyboard functionality
• NumericKeyboard.vue: Virtual keyboard with shuffle capability for enhanced security
• useSecurePin.ts: TypeScript composable function that manages PIN state and masking
• constants.ts: TypeScript types and default configuration values

Props

Prop	Type	Default	Description
maxLength	number	5	Maximum PIN length
isError	boolean	false	Shows error styling when true
errorMessage	string	""	Error message to display
placeholder	string	"Enter PIN"	Placeholder text when empty
isEnableShuffle	boolean	true	Randomize keypad numbers for additional security
showKeyboard	boolean	true	Show keyboard when component loads
title	string	"Use this keyboard to enter your PIN"	Title above virtual keyboard
clearLabel	string	"Clear"	Label for the clear button

Events

Event	Payload Type	Description
callbackEvent	PinEventPayload	Emitted when PIN value changes or clears

// PinEventPayload interface
interface PinEventPayload {
  pin: string;       // Actual PIN value (e.g. "1234")
  pinMasked: string; // Masked PIN value (e.g. "****")
}

Security Features

• PIN Masking: PIN is automatically masked with asterisks to protect sensitive information
• Virtual Keyboard: Prevents keylogging attacks by using an on-screen keyboard
• Keyboard Shuffling: Option to randomize numbers on the keypad for enhanced security
• No DOM Storage: PIN values are kept in memory and not stored in the DOM
• Click Outside Detection: Keyboard automatically closes when clicking outside the component

Customization

The component uses BEM-based CSS classes which you can target for styling. Below are the key CSS selectors you can customize:

Key CSS Classes for Customization

SecurePin Component

• .pin__field - The main input field container
• .pin__field--error - Error state styling
• .pin__error - Error message text
• .pin__display - PIN display area

NumericKeyboard Component

• .numeric-keyboard - Main keyboard container
• .numeric-keyboard__button - Individual number keys
• .numeric-keyboard__button--clear - Clear button

Using Scoped Styles in Vue Component

When using the component in Vue files with scoped styles, remember to use the :deep() selector (Vue 3) to target the component's internal elements.

<style scoped>
/* Target the pin field container */
:deep(.pin__field) {
  border-color: #3498db;
}

/* Target the keyboard buttons */
:deep(.numeric-keyboard__button) {
  background-color: #f8f9fa;
}
</style>

TypeScript Support

This package includes full TypeScript support with:

• Type definitions for all props, events, and methods
• Type-safe component usage
• Exported interfaces for payload objects
• Complete IDE autocompletion
• Optimized for Node.js 20 LTS and modern TypeScript features

// Example of importing types
import { SecurePin } from '@engr-lukman/vue-secure-pin';
import type {
  SecurePinProps,
  PinEventPayload,
  SecurePinExpose
} from '@engr-lukman/vue-secure-pin';

// Type-safe component ref
const pinComponent = ref<InstanceType<typeof SecurePin> | null>(null);

// Access exposed methods with proper types
const clearPin = () => {
  pinComponent.value?.clearHandler();
};

License

MIT © 2025 Mohammad Lukman Hussain
