futoin-executor

Stability: 3 - Stable

About

Documentation --> FutoIn Guide

FutoIn Executor is a peer which processes a request - handles a FutoIn interface method as described in FTN3: FutoIn Interface Definition. It is not necessary a server - e.g. client may handle callback request from server.

Strict FutoIn interface (iface) definition and transport protocol is defined in FTN3 spec mentioned above. As it is based on JSON, both client and server can be implemented in a few minutes almost in any technology. However, Invoker and Executor concept provide significant benefits for efficiency, reliability and error control.

Executor class is the core which encapsulate pure FutoIn Executor logic. It can be extended to platform-specific implementation (e.g. Browser or Node)

The primary communication channel is WebSockets and HTTP as secondary. Large raw data upload and download is also supported through HTTP(S) only.

Executor - neutral Executor concept logic NodeExecutor - available only if used in Node.js

Note: Invoker and Executor are platform/technology-neutral concepts. The implementation is already available in JS and PHP. Hopefully, others are upcoming

Features

• Microservice implementation with zero boilerplates
• Easy scaling from single monolithic process to cluster per microservice
• Universal in-process, WebSockets and HTTP request handling
• REST-like HTTP integration (mapping of path components and parameters to message structure)
• Raw data for request and response (with HTTP fallback)
• Callback requests for bi-directional channels like (WebSockets, in-process)
• Advanced fair resource usage / DoS protection limits based on client source address
  • message limit control
  • max concurrent requests with queuing limits
  • max requests per period with queuing limits
  • optional limit aggregation per network address prefix
  • advanced efficient limit config selection using futoin-ipset
• API specification enforcement (defined in human-friendly FTN3 format)
  • works even for in-process calls and covers JS type safety issues
  • checks parameters with optional default value substitution
  • checks result
  • checks advanced message lengths as per FTN3 v1.8
  • checks exception types to avoid exposure of internal information
  • strict semver-like interface versioning - implicit backward compatibility support
  • transport security, authentication and authorization are integrated as well
  • optional HMAC signing
• High performance and low memory usage

FutoIn reference implementation

Reference implementation of:

FTN6: FutoIn Executor Concept
Version: 1.7

FTN3: FutoIn Interface Definition
Version: 1.9

FTN5: FutoIn HTTP integration
Version: 1.3

FTN4: FutoIn Interface - Ping-Pong
Version: 1.0 (service)

• Spec: FTN6: Interface Executor Concept v1.x
• Spec: FTN3: FutoIn Interface Definition v1.x
• Spec: FTN5: FutoIn HTTP integration v1.x
• Spec: FTN4: FutoIn Interface - Ping-Pong v1.x

Author: Andrey Galkin

Installation for Node.js

Command line:

$ npm install futoin-executor --save

or

$ yarn add futoin-executor

Hint: checkout FutoIn CID for all tools setup.

All public classes can be accessed through module:

var Executor = require('futoin-executor').Executor;

or included modular way, e.g.:

var Executor = require('futoin-executor/Executor');

Browser installation

Pre-built ES5 CJS modules are available under es5/. These modules can be used with webpack without transpiler - default "browser" entry point points to ES5 version.

Webpack dists are also available under dist/ folder, but their usage should be limited to sites without build process.

Warning: check AsyncSteps and AsyncEvent polyfill for older browsers.

The following globals are available:

• SimpleCCM - global reference to futoin-invoker.SimpleCCM class
• AdvancedCCM - global reference to futoin-invoker.AdvancedCCM class
• futoin.Invoker - global reference to futoin-invoker module

Examples

The best examples are live projects:

• futoin-database - neutral database query & transaction concept
• futoin-eventstream - DB transaction focused event system
• futoin-xferengine - very complex bank-grade financial transaction engine

Please note that the examples here expect interface definition files listed below. All sources are available under examples/ folder.

Server implementation example

var AdvancedCCM = require( 'futoin-invoker/AdvancedCCM' );
var NodeExecutor = require( 'futoin-executor/NodeExecutor' );
var async_steps = require( 'futoin-asyncsteps' );

// Initialize CCM
var ccm = new AdvancedCCM( { specDirs : __dirname } );

// Initialize Node.js Executor implementation
var executor = new NodeExecutor(
    ccm,
    {
        specDirs : __dirname,
        httpAddr : 'localhost',
        httpPort : 3000,
        httpPath : '/api/'
    }
);
executor.on( 'notExpected', function( err, error_info ){
    console.log( 'Server: ' + err + ': ' + error_info );
} );

// Normally, you would want to define one in separate module
var service_impl = {
    getProgress : function( as, reqinfo )
    {
        var p = reqinfo.params();

        if ( reqinfo.params().resource === 'MyResource' )
        {
            as.success( { progress : 75 } )
        }
        else
        {
            as.error( 'InvalidResource' );
        }
    },

    subscribeProgress : function( as, reqinfo )
    {
        var p = reqinfo.params();

        if ( reqinfo.params().resource !== 'MyResource' )
        {
            as.error( 'InvalidResource' );
        }

        var channel = reqinfo.channel();
        channel.register( as, 'org.example.receiver:1.0' );

        as.add( function( as )
        {
            var iface = channel.iface( 'org.example.receiver:1.0' );
            reqinfo.result().ok = true;

            // Stupid simple scheduling of events to be sent
            //---
            var add_progress = function( progress, delay )
            {
                setTimeout( function(){
                    async_steps().add( function( as ){
                        iface.progressEvent( as, 'MyResource', progress );
                    } )
                    .execute();
                }, delay );
            };

            for ( var i = 0; i <= 10; ++i )
            {
                add_progress( i * 10, i * 100 );
            }
            //---
        } );
    }
};

// Register Service implementation
async_steps()
.add(
    function( as )
    {
        executor.register( as, 'org.example.service:1.0', service_impl );
    },
    function( as, err )
    {
        console.log( err + ': ' + as.state.error_info );
        console.log( as.state.last_exception.stack );
    }
)
.execute();

Polling client implementation example

var async_steps = require( 'futoin-asyncsteps' );
var AdvancedCCM = require( 'futoin-invoker/AdvancedCCM' );

var ccm = new AdvancedCCM( { specDirs : [ __dirname ] } );

async_steps()
// Do it once for program's entire life time
.add(
    function( as )
    {
        // Register interface and endpoint
        ccm.register( as, 'myservice',
                      'org.example.service:1.0',
                      'http://localhost:3000/api/' );
    },
    function( as, err )
    {
        console.log( err + ': ' + as.state.error_info );
        console.log( as.state.last_exception.stack );
    }
)
// Regular service call
.add(
    function( as )
    {
        var myservice = ccm.iface( 'myservice' );

        // equal to myservice.call( as, 'getProgress', { progress: 'MyResource' } );
        myservice.getProgress( as, 'MyResource' );

        as.add( function( as, res ){
            // Use result
            console.log( 'Progress: ' + res.progress );
        } );
    },
    function( as, err )
    {
        // Handle error
        console.log( err + ': ' + as.state.error_info );
    }
)
.execute();

Event receiving client implementation example

var async_steps = require( 'futoin-asyncsteps' );
var AdvancedCCM = require( 'futoin-invoker/AdvancedCCM' );
var Executor = require( 'futoin-executor/Executor' );

var opts = { specDirs : __dirname };
var ccm = new AdvancedCCM( opts );
var client_executor = new Executor( ccm, opts );

async_steps()
// Do it once for program's entire life time
.add(
    function( as )
    {
        // Register interface and endpoint
        ccm.register(
                as,
                'myservice',
                'org.example.service:1.0',
                'ws://localhost:3000/api/',
                null,
                {
                    executor : client_executor
                }
        );

        // Register client-side Executor Service
        client_executor.register(
                as,
                'org.example.receiver:1.0',
                {
                    progressEvent: function( as, reqinfo )
                    {
                        var progress = reqinfo.params().progress;
                        console.log( 'Progress: ' + progress );

                        if ( progress >= 100 )
                        {
                            ccm.close();
                        }
                    }
                }
        );

        // Subscribe for events
        as.add( function( as )
        {
            // Note: it is a sub-step as we need to wait for
            // registration to complete
            var myservice = ccm.iface( 'myservice' );

            // equal to myservice.call( as, 'subscribeProgress',
            // { progress: 'MyResource' } );
            myservice.subscribeProgress( as, 'MyResource' );
        } );
    },
    function( as, err )
    {
        console.log( err + ': ' + as.state.error_info );
        console.log( as.state.last_exception.stack );
    }
)
.execute();

Example output of execution

Starting Example Server
Starting Example Client
Progress: 75
Starting Example Client with Callback
Progress: 0
Progress: 10
Progress: 20
Progress: 30
Progress: 40
Progress: 50
Progress: 60
Progress: 70
Progress: 80
Progress: 90
Progress: 100

FutoIn iface definitions

Please see FTN3: FutoIn Interface Definition v1.x for all advanced features.

org.example.types-1.0-iface.json

This one is only used to share Type definitions. It does not participate in inheritance

{
    "iface" : "org.example.types",
    "version" : "1.0",
    "ftn3rev" : "1.1",
    "types" : {
        "Percent" : {
            "type" : "integer",
            "min" : 0,
            "max" : 100
        }
    },
    "desc" : "Shared interface to define common types"
}

org.example.service-1.0-iface.json

Actual Server-side Service definition

{
    "iface" : "org.example.service",
    "version" : "1.0",
    "ftn3rev" : "1.1",
    "imports" : [
        "org.example.types:1.0"
    ],
    "funcs" : {
        "getProgress" : {
            "params" : {
                "resource" : {
                    "type" : "string"
                }
            },
            "result" : {
                "progress" : {
                    "type" : "Percent"
                }
            },
            "throws" : [
                "InvalidResource"
            ]
        },
        "subscribeProgress" : {
            "params" : {
                "resource" : {
                    "type" : "string"
                }
            },
            "result" : {
                "ok" : {
                    "type" : "boolean"
                }
            },
            "throws" : [
                "InvalidResource"
            ]
        }
    },
    "requires" : [
        "AllowAnonymous"
    ],
    "desc" : "Service-side Service"
}

org.example.receiver-1.0-iface.json

Client-side Service for bi-directional transport channels, like WebSockets.

{
    "iface" : "org.example.receiver",
    "version" : "1.0",
    "ftn3rev" : "1.1",
    "imports" : [
        "org.example.types:1.0"
    ],
    "funcs" : {
        "progressEvent" : {
            "params" : {
                "resource" : {
                    "type" : "string"
                },
                "progress" : {
                    "type" : "Percent"
                }
            },
            "desc" : "Progress receiving event callback"
        }
    },
    "requires" : [
        "AllowAnonymous"
    ],
    "desc" : "Client-side Service"
}

API documentation

The concept is described in FutoIn specification: FTN6: Interface Executor Concept v1.x

Modules

futoin-executor

Classes

BasicAuthFace

BasicAuth is not official spec - it is a temporary solution until FTN8 Security Concept is finalized

BasicAuthService

BasicService is not official spec - it is a temporary solution until FTN8 Security Concept is finalized

BrowserExecutorOptions ⇐ ExecutorOptions

BrowserExecutor

Browser Executor with HTML5 Web Messaging as incoming transport.

It allows communication across open pages (frames/tabs/windows) inside client browser.

ChannelContext

Channel Context normally accessible through RequestInfo object.

DerivedKey

Derived Key interface for planned FTN8 Master key management.

A dummy so far.

ExecutorOptions

Executor

An abstract core implementing pure FTN6 Executor logic.

LegacySecurityProvider

This functionality is provided to provide historical not standard BasicAuth interface. Use of this approach is discouraged.

NodeExecutorOptions ⇐ ExecutorOptions

NodeExecutor

Executor implementation for Node.js/io.js with HTTP and WebSockets transport

PingService

Implementation of futoin.ping & futoin.anonping interface

Designed to be used as imported part of larger interfaces.

RequestInfoConst

RequestInfo

RequestInfo object as defined in FTN6

SecurityProvider

Generic security provider interface

SourceAddress

Source Address representation

UserInfo

Class representing user information

Members

FutoInExecutor

window.FutoInExecutor - Browser-only reference to futoin-executor

Executor

window.futoin.Executor - Browser-only reference to futoin-executor

BrowserExecutor

window.BrowserExecutor - Browser-only reference to futoin-executor.BrowserExecutor

Constants

UserInfoConst

Pseudo-class for documenting UserInfo detail fields as defined in FTN8 spec

futoin-executor

BasicAuthFace

BasicAuth is not official spec - it is a temporary solution until FTN8 Security Concept is finalized

Kind: global class

BasicAuthFace.register(as, ccm, endpoint, [credentials], [options])

BasicAuth interface registration helper

Kind: static method of BasicAuthFace

Param	Type	Default	Description
as	AsyncSteps		step interface
ccm	AdvancedCCM		CCM instance
endpoint	string		endpoint URL
[credentials]	*		see CCM register()
[options]	object	{}	registration options
[options.version]	string	"1.0"	iface version

BasicAuthService

BasicService is not official spec - it is a temporary solution until FTN8 Security Concept is finalized

Kind: global class

• BasicAuthService
  • instance
    • .addUser(user, secret, details, [system_user])
    • ._getUser(as, user)
    • ._getUserByID(as, local_id)
    • .addUser(user, secret, details, [system_user])
  • static
    • .register(as, executor) ⇒ BasicAuthService

basicAuthService.addUser(user, secret, details, [system_user])

Register users statically right after registration

Kind: instance method of BasicAuthService

Param	Type	Description
user	string	user name
secret	string	user secret (either password or raw key for HMAC)
details	object	user details the way as defined in FTN8
[system_user]	boolean	is system user

basicAuthService._getUser(as, user)

Get by name. Override, if needed.

Kind: instance method of BasicAuthService
Note: as result: {object} user object or null (through as)

Param	Type	Description
as	AsyncSteps	steps interface
user	string	user name

basicAuthService._getUserByID(as, local_id)

Get by ID. Override, if needed.

Kind: instance method of BasicAuthService
Note: as result: {object} user object or null (through as)

Param	Type	Description
as	AsyncSteps	steps interfaces
local_id	number	local ID

basicAuthService.addUser(user, secret, details, [system_user])

Register users statically right after registration

Kind: instance method of BasicAuthService

Param	Type	Default	Description
user	string		user name
secret	string		user secret (either password or raw key for HMAC)
details	object		user details the way as defined in FTN8
[system_user]	boolean	false	is system user

BasicAuthService.register(as, executor) ⇒ BasicAuthService

BasicAuthService registration helper

Kind: static method of BasicAuthService
Returns: BasicAuthService - reference to implementation instance (to register users)

Param	Type	Description
as	AsyncSteps	steps interface
executor	Executor	executor instance

BrowserExecutorOptions ⇐ ExecutorOptions

Kind: global class
Extends: ExecutorOptions

• BrowserExecutorOptions ⇐ ExecutorOptions
  • new BrowserExecutorOptions()
  • .clientTimeoutMS
  • .allowedOrigins

new BrowserExecutorOptions()

Pseudo-class for BrowserExecutor options documentation

BrowserExecutorOptions.clientTimeoutMS

Client timeout MS

Kind: static property of BrowserExecutorOptions
Default: 600

BrowserExecutorOptions.allowedOrigins

List of allowed page origins for incoming connections. It is MANDATORY for security reasons.

Example:

• 'http://localhost:8000'
• 'http://example.com'

Kind: static property of BrowserExecutorOptions
Default: []

BrowserExecutor

Browser Executor with HTML5 Web Messaging as incoming transport.

It allows communication across open pages (frames/tabs/windows) inside client browser.

Kind: global class

new BrowserExecutor(ccm, opts)

Param	Type	Description
ccm	AdvancedCCM	CCM ref
opts	BrowserExecutorOptions	executor options

ChannelContext

Channel Context normally accessible through RequestInfo object.

Kind: global class

• ChannelContext
  • new ChannelContext(executor)
  • .type() ⇒ string
  • .isStateful() ⇒ Boolean
  • .onInvokerAbort(callable, [user_data])
  • .register(as, ifacever, options)
  • .iface(ifacever) ⇒ NativeIface

new ChannelContext(executor)

Param	Type	Description
executor	Executor	reference to associated executor

channelContext.type() ⇒ string

Get type of channel

Standard values: HTTP, WS, BROWSER, TCP, UDP, UNIX

Kind: instance abstract method of ChannelContext
Returns: string - arbitrary string, see FTN6

channelContext.isStateful() ⇒ Boolean

Check if transport is stateful (e.g. WebSockets)

Kind: instance method of ChannelContext
Returns: Boolean - true, if context object is persistent across requests in the same session

channelContext.onInvokerAbort(callable, [user_data])

Set invoker abort handler.

Kind: instance method of ChannelContext
Note: It should be possible to call multiple times setting multiple callbacks.
Note: The callback is set for lifetime of the channel - do not use it on every request!

Param	Type	Description
callable	function	callback
[user_data]	any	optional parameter to pass to callable

channelContext.register(as, ifacever, options)

Register Invoker interface on bi-directional channels to make calls from Server to Client.

Kind: instance method of ChannelContext
See: AdvancedCCM.register

Param	Type	Description
as	AsyncSteps	steps interface
ifacever	string	standard iface:version notation
options	object	standard Invoker options

channelContext.iface(ifacever) ⇒ NativeIface

Get previously registered interface on bi-directional channel.

NOTE: unlike CCM, there is no point for local alias name as Invoker can have only a single ClientExecutor which can have only a single instance implementing specified iface:version.

Kind: instance method of ChannelContext
Returns: NativeIface - - native interface
See: AdvancedCCM.iface

Param	Type	Description
ifacever	string	standard iface:version notation

DerivedKey

Derived Key interface for planned FTN8 Master key management.

A dummy so far.

Kind: global class

• DerivedKey
  • new DerivedKey(ccm, base_id, sequence_id)
  • .baseID() ⇒ integer
  • .sequenceID() ⇒ integer
  • .encrypt(as, data) ⇒ Buffer
  • .decrypt(as, data) ⇒ Buffer

new DerivedKey(ccm, base_id, sequence_id)

Param	Type	Description
ccm	AdvancedCCM	reference to CCM
base_id	integer	master key ID
sequence_id	integer	sequence number of the derived key

derivedKey.baseID() ⇒ integer

Get master key ID

Kind: instance method of DerivedKey
Returns: integer - Base ID

derivedKey.sequenceID() ⇒ integer

Get derived key sequence ID

Kind: instance method of DerivedKey
Returns: integer - Sequence ID

derivedKey.encrypt(as, data) ⇒ Buffer

Encrypt data with current derived key. Useful for very senstive information.

Kind: instance method of DerivedKey
Returns: Buffer - encrypted data

Param	Type	Description
as	AsyncSteps	steps interface
data	string | Buffer	to encrypt

derivedKey.decrypt(as, data) ⇒ Buffer

Decrypt data using current derived key

Kind: instance method of DerivedKey
Returns: Buffer - decrypted data

Param	Type	Description
as	AsyncSteps	steps interface
data	Buffer	to decrypt

ExecutorOptions

Kind: global class

• ExecutorOptions
  • new ExecutorOptions()
  • .specDirs
  • .prodMode
  • .reqTimeout
  • .heavyReqTimeout
  • .securityProvider
  • .messageSniffer()

new ExecutorOptions()

Pseudo-class for Executor options documentation

ExecutorOptions.specDirs

Search dirs for spec definition or spec instance directly. It can be single value or array of values. Each value is either path/URL (string) or iface spec instance (object).

Kind: static property of ExecutorOptions
Default: []

ExecutorOptions.prodMode

Production mode - disables some checks without compomising security

Kind: static property of ExecutorOptions
Default: false

ExecutorOptions.reqTimeout

Default request processing timeout

Kind: static property of ExecutorOptions
Default: 5000

ExecutorOptions.heavyReqTimeout

Default request processing timeout for functions marked "heavy". See FTN3

Kind: static property of ExecutorOptions
Default: 60000

ExecutorOptions.securityProvider

FTN8 security interface

Kind: static property of ExecutorOptions

ExecutorOptions.messageSniffer()

Message sniffer callback( iface_info, msg, is_incomming ). Useful for audit logging.

Kind: static method of ExecutorOptions
Default: dummy

Executor

An abstract core implementing pure FTN6 Executor logic.

Kind: global class

• Executor
  • new Executor(ccm, opts)
  • .ccm() ⇒ AdvancedCCM
  • .register(as, ifacever, impl, specdirs)
  • .onEndpointRequest(info, ftnreq, send_executor_rsp)
  • .onInternalRequest(as, info, ftnreq, [upload_data], [download_stream])
  • .process(as)
  • .checkAccess(as, acd)
  • .initFromCache(as)
  • .cacheInit(as)
  • .close([close_cb])
  • .packPayload(coder, msg) ⇒ string
  • "ready"
  • "request"
  • "response"
  • "notExpected"
  • "close"

new Executor(ccm, opts)

Param	Type	Description
ccm	AdvancedCCM	instance of AdvancedCCM
opts	objects	see ExecutorOptions

executor.ccm() ⇒ AdvancedCCM

Get reference to associated AdvancedCCM instance

Kind: instance method of Executor
Returns: AdvancedCCM - CCM ref

executor.register(as, ifacever, impl, specdirs)

Register implementation of specific interface

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface
ifacever	string	standard iface:version notation of interface to be implemented.
impl	object | function	either iface implementation or func( impl, executor )
specdirs	object | array	NOT STANDARD. Useful for direct passing of hardcoded spec definition.

executor.onEndpointRequest(info, ftnreq, send_executor_rsp)

Entry point for Server-originated requests when acting as ClientExecutor

Kind: instance method of Executor
Emits: notExpected, request, response

Param	Type	Description
info	object	raw Invoker interface info
ftnreq	object	FutoIn request object
send_executor_rsp	function	callback( ftnrsp )

executor.onInternalRequest(as, info, ftnreq, [upload_data], [download_stream])

Entry point for in-program originated requests. Process with maximum efficiency (not yet ;)

Kind: instance method of Executor
Emits: notExpected, request, response
Note: AS result: ftnrsp, content-type

Param	Type	Description
as	AsyncSteps	steps interface
info	object	raw Invoker interface info
ftnreq	object	FutoIn request object
[upload_data]	object	upload stream, if any
[download_stream]	object	download stream, if any

executor.process(as)

Standard entry point used by subclasses. Do full cycle of request processing, including all security checks

NOTE: as.state.reqinfo must point to valid instance of RequestInfo

Kind: instance method of Executor
Emits: notExpected, request, response

Param	Type	Description
as	AsyncSteps	steps interface

executor.checkAccess(as, acd)

Shortcut to check access through #acl interface.

NOTE: as.state.reqinfo must point to valid instance of RequestInfo

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface
acd	string	access control descriptor

executor.initFromCache(as)

NOT IMPLEMENTED, DO NOT USE. Just a compliance with the Executor interface from spec.

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface

executor.cacheInit(as)

NOT IMPLEMENTED, DO NOT USE. Just a compliance with the Executor interface from spec.

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface

executor.close([close_cb])

Shutdown Executor and stop whole processing

Kind: instance method of Executor
Emits: close

Param	Type	Default	Description
[close_cb]	callable		callback to execute after Executor shutdown

executor.packPayload(coder, msg) ⇒ string

Not standard. Pack message object into JSON representation. If safe limit of 64K is exceeded then error is raised.

Kind: instance method of Executor
Returns: string - string representation of the message
Emits: notExpected

Param	Type	Description
coder	MessageCoder	message coder instance
msg	object	message to encode into JSON

"ready"

May be fired in derived Executors to signal readiness ()

Kind: event emitted by Executor

"request"

Fired when request processing is started. ( reqinfo, rawreq )

Kind: event emitted by Executor

"response"

Fired when request processing is started. ( reqinfo, rawreq )

Kind: event emitted by Executor

"notExpected"

Fired when not expected error occurs ( errmsg, error_info, last_exception, async_stack )

Kind: event emitted by Executor

"close"

Fired when Executor is shutting down. ()

Kind: event emitted by Executor

LegacySecurityProvider

This functionality is provided to provide historical not standard BasicAuth interface. Use of this approach is discouraged.

Kind: global class

new LegacySecurityProvider(as, ccm, secprov)

C-tor

Param	Type	Default	Description
as	AsyncSteps		AsyncSteps interface
ccm	AdvancedCCM		CCM instance
secprov	SecurityProvider		optional secprov for chaining

NodeExecutorOptions ⇐ ExecutorOptions

Kind: global class
Extends: ExecutorOptions

• NodeExecutorOptions ⇐ ExecutorOptions
  • new NodeExecutorOptions()
  • .httpServer
  • .httpAddr
  • .httpPort
  • .httpPath
  • .httpBacklog
  • .secureChannel
  • .trustProxy
  • .enableLimiter
  • .cleanupLimitsMS
  • .cleanupConnMS
  • .limitCacheSize
  • .limitConf
  • .addressLimitMap
  • .secureObjectPrototype

new NodeExecutorOptions()

Pseudo-class for NodeExecutor options documentation

NodeExecutorOptions.httpServer

Provide a pre-configured HTTP server instance or use httpPort [& httpAddr] options

Kind: static property of NodeExecutorOptions
Default:

NodeExecutorOptions.httpAddr

Bind address for internally created HTTP server

Kind: static property of NodeExecutorOptions
Default:

NodeExecutorOptions.httpPort

Bind port for internally created HTTP server

Kind: static property of NodeExecutorOptions
Default:

NodeExecutorOptions.httpPath

Path to server FutoIn request on.

NOTE: if httpServer is provided than all not related requests are silently ignored. Otherwise, immediate error is raised if request path does not match httpPath.

Kind: static property of NodeExecutorOptions
Default: /

NodeExecutorOptions.httpBacklog

Option to configure internally created server backlog

Kind: static property of NodeExecutorOptions
Default:

NodeExecutorOptions.secureChannel

If true, if incoming transport as seen is 'SecureChannel', see FTN3. Useful with reverse proxy and local connections.

Kind: static property of NodeExecutorOptions
Default: false

NodeExecutorOptions.trustProxy

If true, X-Real-IP and X-Forwarded-For will be used as Source Address, if present

Kind: static property of NodeExecutorOptions
Default: false

NodeExecutorOptions.enableLimiter

If true, then request limiter is enabled by default

Kind: static property of NodeExecutorOptions
Default: false

NodeExecutorOptions.cleanupLimitsMS

Interval to run limiter cleanup task for better cache performance and correct reflection of active memory usage.

Kind: static property of NodeExecutorOptions
Default: 60000

NodeExecutorOptions.cleanupConnMS

Interval to run connection cleanup task for WebSockets. If connection is idle for this period then ping is sent. If connection is idle for twice of that period then connection is killed.

Kind: static property of NodeExecutorOptions
Default: 60000

NodeExecutorOptions.limitCacheSize

Auto-detected based posix.getrlimit('nofiles')

Kind: static property of NodeExecutorOptions
Default:

NodeExecutorOptions.limitConf

Startup configuration for NodeExecutor#limitConf(). Please mind it's per v4/v6 scope (prefix length).

Kind: static property of NodeExecutorOptions
Default: {"default":""}

NodeExecutorOptions.addressLimitMap

Startup configuration for NodeExecutor#addressLimitMap()

Kind: static property of NodeExecutorOptions
Default: {}

NodeExecutorOptions.secureObjectPrototype

Controls if SpecTools.secureObjectPrototype() is called upon startup.

Kind: static property of NodeExecutorOptions
Default: true

NodeExecutor

Executor implementation for Node.js/io.js with HTTP and WebSockets transport

Kind: global class

• NodeExecutor
  • new NodeExecutor(ccm, opts)
  • .limitsIPSet ⇒ IPSet
  • .handleHTTPRequest(req, rsp) ⇒ Boolean
  • .handleWSConnection(upgrade_req, ws)
  • .limitConf(name, options)
  • .addressLimitMap(map)

new NodeExecutor(ccm, opts)

Param	Type	Description
ccm	AdvancedCCM	CCM for internal requests
opts	NodeExecutorOptions	executor options

nodeExecutor.limitsIPSet ⇒ IPSet

Access address-limit name ipset for efficient dynamic manipulation

Kind: instance property of NodeExecutor
Returns: IPSet - - ref to static address to limit mapping

nodeExecutor.handleHTTPRequest(req, rsp) ⇒ Boolean

Entry point to process HTTP request

Kind: instance method of NodeExecutor
Returns: Boolean - true on success

Param	Type	Description
req	http.IncomingMessage	incoming HTTP request
rsp	http.ServerResponse	response object

nodeExecutor.handleWSConnection(upgrade_req, ws)

Entry point to process HTTP upgrade request with WebSocket

Kind: instance method of NodeExecutor

Param	Type	Description
upgrade_req	http.IncomingMessage	original HTTP upgrade request
ws	WebSocket	WebSockets connection object

nodeExecutor.limitConf(name, options)

Configure named limits to be used for client's request limiting.

Kind: instance method of NodeExecutor

Param	Type	Description
name	string	name of limit configuration
options	object	see AsyncSteps Limiter class

nodeExecutor.addressLimitMap(map)

Configure static address to limit name map

Kind: instance method of NodeExecutor

Param	Type	Description
map	object	limit-name => list of CIDR addresses pairs

PingService

Implementation of futoin.ping & futoin.anonping interface

Designed to be used as imported part of larger interfaces.

Kind: global class

PingService.register(as, executor) ⇒ PingService

Register futoin.ping interface with Executor

Kind: static method of PingService
Returns: PingService - instance by convention

Param	Type	Description
as	AsyncSteps	steps interface
executor	Executor	executor instance

RequestInfoConst

Kind: global class
See: FTN6 spec

• RequestInfoConst
  • new RequestInfoConst()
  • .INFO_X509_CN
  • .INFO_PUBKEY
  • .INFO_CLIENT_ADDR
  • .INFO_SECURE_CHANNEL
  • .INFO_REQUEST_TIME_FLOAT
  • .INFO_SECURITY_LEVEL
  • .INFO_USER_INFO
  • .INFO_RAW_REQUEST
  • .INFO_RAW_RESPONSE
  • .INFO_DERIVED_KEY
  • .INFO_HAVE_RAW_UPLOAD
  • .INFO_HAVE_RAW_RESULT
  • .INFO_CHANNEL_CONTEXT
  • .SL_ANONYMOUS
  • .SL_INFO
  • .SL_SAFE_OPS
  • .SL_PRIVILEGED_OPS
  • .SL_EXCEPTIONAL_OPS
  • .SL_SYSTEM

new RequestInfoConst()

Pseudo-class for RequestInfo.info field enumeration

RequestInfoConst.INFO_X509_CN

CN field coming from validated client's x509 certificate, if any

Kind: static property of RequestInfoConst
Default: X509_CN

RequestInfoConst.INFO_PUBKEY

Client provided public key, if any

Kind: static property of RequestInfoConst
Default: PUBKEY

RequestInfoConst.INFO_CLIENT_ADDR

Client address

Kind: static property of RequestInfoConst
Default: CLIENT_ADDR
See: SourceAddress

RequestInfoConst.INFO_SECURE_CHANNEL

Boolean, indicates if transport channel is secure

Kind: static property of RequestInfoConst
Default: SECURE_CHANNEL

RequestInfoConst.INFO_REQUEST_TIME_FLOAT

Implementation define timestamp of request start.

NOTE:it may not be related to absolute time. Please see performance-now NPM module.

Kind: static property of RequestInfoConst
Default: REQUEST_TIME_FLOAT

RequestInfoConst.INFO_SECURITY_LEVEL

Authentication, but not authorization, security level.

Kind: static property of RequestInfoConst
See: RequestInfoConst.SL_*

RequestInfoConst.INFO_USER_INFO

User Info object

Kind: static property of RequestInfoConst
See: UserInfo

RequestInfoConst.INFO_RAW_REQUEST

Raw FutoIn request object

Kind: static property of RequestInfoConst

RequestInfoConst.INFO_RAW_RESPONSE

Raw FutoIn response object

Kind: static property of RequestInfoConst

RequestInfoConst.INFO_DERIVED_KEY

Associated Derived Key

Kind: static property of RequestInfoConst
See: DerivedKey

RequestInfoConst.INFO_HAVE_RAW_UPLOAD

Indicates that input transport provided raw upload stream.

NOTE: service implementation should simply try to open RequestInfo.rawInput()

Kind: static property of RequestInfoConst

RequestInfoConst.INFO_HAVE_RAW_RESULT

Indicates that Executor must provide raw response

NOTE: service implementation should simply try to open RequestInfo.rawOutput()

Kind: static property of RequestInfoConst

RequestInfoConst.INFO_CHANNEL_CONTEXT

Associated transport channel context

Kind: static property of RequestInfoConst
See: ChannelContext

RequestInfoConst.SL_ANONYMOUS

Security Level - Anonymous

Kind: static constant of RequestInfoConst
Default: Anonymous
See: RequestInfoConst.INFO_SECURITY_LEVEL

RequestInfoConst.SL_INFO

Security Level - Info

NOTE: it is level of user authentication, but not authorization. This one is equal to HTTP cookie-based authentication.

Kind: static constant of RequestInfoConst
Default: Info
See: RequestInfoConst.INFO_SECURITY_LEVEL

RequestInfoConst.SL_SAFE_OPS

Security Level - SafeOps

NOTE: it is level of user authentication, but not authorization. This one is equal to HTTP Basic Auth.

Kind: static constant of RequestInfoConst
Default: SafeOps
See: RequestInfoConst.INFO_SECURITY_LEVEL

RequestInfoConst.SL_PRIVILEGED_OPS

Security Level - PrivilegedOps

NOTE: it is level of user authentication, but not authorization. This one equals to multi-factor authentication and signed requests.

Kind: static constant of RequestInfoConst
Default: PrivilegedOps
See: RequestInfoConst.INFO_SECURITY_LEVEL

RequestInfoConst.SL_EXCEPTIONAL_OPS

Security Level - ExceptionalOps

NOTE: it is level of user authentication, but not authorization. This one equals to multi-factor authentication for each action and signed requests.

Kind: static constant of RequestInfoConst
Default: ExceptionalOps
See: RequestInfoConst.INFO_SECURITY_LEVEL

RequestInfoConst.SL_SYSTEM

Security Level - System

NOTE: it is level of user authentication, but not authorization. This one equals to internal system authorization. User never gets such security level.

Kind: static constant of RequestInfoConst
Default: System
See: RequestInfoConst.INFO_SECURITY_LEVEL

RequestInfo

RequestInfo object as defined in FTN6

Kind: global class

• RequestInfo
  • new RequestInfo(executor, rawreq)
  • .params() ⇒ object
  • .result(replace) ⇒ object
  • .rawInput() ⇒ object
  • .rawOutput() ⇒ object
  • .executor() ⇒ Executor
  • .ccm() ⇒ AdvancedCCM
  • .channel() ⇒ ChannelContext
  • .cancelAfter(time_ms)

new RequestInfo(executor, rawreq)

Param	Type	Description
executor	Executor	_
rawreq	object | string	raw request

requestInfo.params() ⇒ object

Get reference to input params

Kind: instance method of RequestInfo
Returns: object - parameter holder

requestInfo.result(replace) ⇒ object

Get reference to output

Kind: instance method of RequestInfo
Returns: object - result variable holder

Param	Type	Description
replace	*	replace result object

requestInfo.rawInput() ⇒ object

Get reference to input stream

Kind: instance method of RequestInfo
Returns: object - raw input stream
Throws:

• RawInputError

requestInfo.rawOutput() ⇒ object

Get reference to output stream

Kind: instance method of RequestInfo
Returns: object - raw output stream
Throws:

• RawOutputError

requestInfo.executor() ⇒ Executor

Get reference to associated Executor instance

Kind: instance method of RequestInfo
Returns: Executor - _

requestInfo.ccm() ⇒ AdvancedCCM

Get reference to associated Executor's CCM instance

Kind: instance method of RequestInfo
Returns: AdvancedCCM - _

requestInfo.channel() ⇒ ChannelContext

Get reference to channel context

Kind: instance method of RequestInfo
Returns: ChannelContext - _

requestInfo.cancelAfter(time_ms)

Set overall request processing timeout in microseconds.

NOTE: repeat calls override previous value

Kind: instance method of RequestInfo

Param	Type	Description
time_ms	float	set automatic request timeout after specified value of microseconds. 0 - disables timeout

SecurityProvider

Generic security provider interface

Kind: global class

• SecurityProvider
  • .checkAuth(as, reqinfo, reqmsg, sec)
  • .signAuto(as, reqinfo, rspmsg) ⇒ boolean
  • .isSigned(reqinfo) ⇒ boolean
  • .checkAccess(as, reqinfo, acd)
  • ._setUser(as, reqinfo, seclvl, auth_info)
  • ._normalizeQueryParams(as, reqinfo)

securityProvider.checkAuth(as, reqinfo, reqmsg, sec)

Check request authentication.

Kind: instance method of SecurityProvider

Param	Type	Description
as	AsyncSteps	AsyncSteps interface
reqinfo	RequestInfo	extended request info
reqmsg	object	request message as is
sec	array	reqmsg.sec field split by ':'

securityProvider.signAuto(as, reqinfo, rspmsg) ⇒ boolean

Check if response signature is required and perform signing.

Kind: instance method of SecurityProvider
Returns: boolean - true, if signature is set

Param	Type	Description
as	AsyncSteps	AsyncSteps interface
reqinfo	RequestInfo	extended request info
rspmsg	object	response message as is

securityProvider.isSigned(reqinfo) ⇒ boolean

Check if request is signed as in MessageSignature constraint.

Kind: instance method of SecurityProvider
Returns: boolean - true, if signed

Param	Type	Description
reqinfo	RequestInfo	extended request info

securityProvider.checkAccess(as, reqinfo, acd)

Check access through Access Control concept

Kind: instance method of SecurityProvider

Param	Type	Description
as	AsyncSteps	AsyncSteps interface
reqinfo	RequestInfo	extended request info
acd	string | array	access control descriptor

securityProvider._setUser(as, reqinfo, seclvl, auth_info)

A special helper to set authenticated user info

Kind: instance method of SecurityProvider

Param	Type	Default	Description
as	AsyncSteps		AsyncSteps interface
reqinfo	RequestInfo		extended request info
seclvl	string		security level
auth_info	object		authentication info
auth_info.local_id	integer | string		Local User ID
auth_info.global_id	string		Global User ID
[auth_info.details]	object		user details

securityProvider._normalizeQueryParams(as, reqinfo)

Normalize parameters passed through HTTP query. It's important to call this before MAC checking.

Kind: instance method of SecurityProvider

Param	Type	Description
as	AsyncSteps	AsyncSteps interface
reqinfo	RequestInfo	extended request info

SourceAddress

Source Address representation

Kind: global class

• SourceAddress
  • new SourceAddress(type, [host], port)
  • .asString() ⇒ string

new SourceAddress(type, [host], port)

Param	Type	Description
type	string	Type of address
[host]	string	machine address, if applicable
port	integer | string	port or path, if applicable

sourceAddress.asString() ⇒ string

Get a stable string representation

Kind: instance method of SourceAddress
Returns: string - string representation

UserInfo

Class representing user information

Kind: global class

• UserInfo
  • new UserInfo(ccm, local_id, global_id, details)
  • .localID() ⇒ integer
  • .globalID() ⇒ string
  • .details(as, [user_field_identifiers]) ⇒ AsyncSteps

new UserInfo(ccm, local_id, global_id, details)

Param	Type	Description
ccm	AdvancedCCM	reference to CCM
local_id	integer	local unique ID
global_id	string	global unique ID
details	object	user info fields, see UserInfoConst

userInfo.localID() ⇒ integer

Get local unique ID

Kind: instance method of UserInfo
Returns: integer - Local ID

userInfo.globalID() ⇒ string

Get local global ID

Kind: instance method of UserInfo
Returns: string - Global ID

userInfo.details(as, [user_field_identifiers]) ⇒ AsyncSteps

Get user info details

Kind: instance method of UserInfo
Returns: AsyncSteps - for easy chaining. {object} with details through as.success()

Param	Type	Description
as	AsyncSteps	steps interface
[user_field_identifiers]	object	field list to get

FutoInExecutor

window.FutoInExecutor - Browser-only reference to futoin-executor

Kind: global variable

Executor

window.futoin.Executor - Browser-only reference to futoin-executor

Kind: global variable

• Executor
  • new Executor(ccm, opts)
  • .ccm() ⇒ AdvancedCCM
  • .register(as, ifacever, impl, specdirs)
  • .onEndpointRequest(info, ftnreq, send_executor_rsp)
  • .onInternalRequest(as, info, ftnreq, [upload_data], [download_stream])
  • .process(as)
  • .checkAccess(as, acd)
  • .initFromCache(as)
  • .cacheInit(as)
  • .close([close_cb])
  • .packPayload(coder, msg) ⇒ string
  • "ready"
  • "request"
  • "response"
  • "notExpected"
  • "close"

new Executor(ccm, opts)

Param	Type	Description
ccm	AdvancedCCM	instance of AdvancedCCM
opts	objects	see ExecutorOptions

executor.ccm() ⇒ AdvancedCCM

Get reference to associated AdvancedCCM instance

Kind: instance method of Executor
Returns: AdvancedCCM - CCM ref

executor.register(as, ifacever, impl, specdirs)

Register implementation of specific interface

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface
ifacever	string	standard iface:version notation of interface to be implemented.
impl	object | function	either iface implementation or func( impl, executor )
specdirs	object | array	NOT STANDARD. Useful for direct passing of hardcoded spec definition.

executor.onEndpointRequest(info, ftnreq, send_executor_rsp)

Entry point for Server-originated requests when acting as ClientExecutor

Kind: instance method of Executor
Emits: notExpected, request, response

Param	Type	Description
info	object	raw Invoker interface info
ftnreq	object	FutoIn request object
send_executor_rsp	function	callback( ftnrsp )

executor.onInternalRequest(as, info, ftnreq, [upload_data], [download_stream])

Entry point for in-program originated requests. Process with maximum efficiency (not yet ;)

Kind: instance method of Executor
Emits: notExpected, request, response
Note: AS result: ftnrsp, content-type

Param	Type	Description
as	AsyncSteps	steps interface
info	object	raw Invoker interface info
ftnreq	object	FutoIn request object
[upload_data]	object	upload stream, if any
[download_stream]	object	download stream, if any

executor.process(as)

Standard entry point used by subclasses. Do full cycle of request processing, including all security checks

NOTE: as.state.reqinfo must point to valid instance of RequestInfo

Kind: instance method of Executor
Emits: notExpected, request, response

Param	Type	Description
as	AsyncSteps	steps interface

executor.checkAccess(as, acd)

Shortcut to check access through #acl interface.

NOTE: as.state.reqinfo must point to valid instance of RequestInfo

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface
acd	string	access control descriptor

executor.initFromCache(as)

NOT IMPLEMENTED, DO NOT USE. Just a compliance with the Executor interface from spec.

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface

executor.cacheInit(as)

NOT IMPLEMENTED, DO NOT USE. Just a compliance with the Executor interface from spec.

Kind: instance method of Executor

Param	Type	Description
as	AsyncSteps	steps interface

executor.close([close_cb])

Shutdown Executor and stop whole processing

Kind: instance method of Executor
Emits: close

Param	Type	Default	Description
[close_cb]	callable		callback to execute after Executor shutdown

executor.packPayload(coder, msg) ⇒ string

Not standard. Pack message object into JSON representation. If safe limit of 64K is exceeded then error is raised.

Kind: instance method of Executor
Returns: string - string representation of the message
Emits: notExpected

Param	Type	Description
coder	MessageCoder	message coder instance
msg	object	message to encode into JSON

"ready"

May be fired in derived Executors to signal readiness ()

Kind: event emitted by Executor

"request"

Fired when request processing is started. ( reqinfo, rawreq )

Kind: event emitted by Executor

"response"

Fired when request processing is started. ( reqinfo, rawreq )

Kind: event emitted by Executor

"notExpected"

Fired when not expected error occurs ( errmsg, error_info, last_exception, async_stack )

Kind: event emitted by Executor

"close"

Fired when Executor is shutting down. ()

Kind: event emitted by Executor

BrowserExecutor

window.BrowserExecutor - Browser-only reference to futoin-executor.BrowserExecutor

Kind: global variable

new BrowserExecutor(ccm, opts)

Param	Type	Description
ccm	AdvancedCCM	CCM ref
opts	BrowserExecutorOptions	executor options

UserInfoConst

Pseudo-class for documenting UserInfo detail fields as defined in FTN8 spec

Kind: global constant

• UserInfoConst
  • .INFO_Login
  • .INFO_Nick
  • .INFO_FirstName
  • .INFO_FullName
  • .INFO_DateOfBirth
  • .INFO_TimeOfBirth
  • .INFO_ContactEmail
  • .INFO_ContactPhone
  • .INFO_HomeAddress
  • .INFO_WorkAddress
  • .INFO_Citizenship
  • .INFO_GovernmentRegID
  • .INFO_AvatarURL

UserInfoConst.INFO_Login

Login Name

Kind: static constant of UserInfoConst
Default: Login

UserInfoConst.INFO_Nick

Nick Name

Kind: static constant of UserInfoConst
Default: Nick

UserInfoConst.INFO_FirstName

First Name

Kind: static constant of UserInfoConst
Default: FirstName

UserInfoConst.INFO_FullName

Full Name

Kind: static constant of UserInfoConst
Default: FullName

UserInfoConst.INFO_DateOfBirth

Date if birth in ISO "YYYY-MM-DD" format

Kind: static constant of UserInfoConst
Default: DateOfBirth

UserInfoConst.INFO_TimeOfBirth

Date if birth in ISO "HH:mm:ss" format, can be truncated to minutes

Kind: static constant of UserInfoConst
Default: TimeOfBirth

UserInfoConst.INFO_ContactEmail

E-mail for contacts

Kind: static constant of UserInfoConst
Default: ContactEmail

UserInfoConst.INFO_ContactPhone

Phone for contacts

Kind: static constant of UserInfoConst
Default: ContactPhone

UserInfoConst.INFO_HomeAddress

Home address

Kind: static constant of UserInfoConst
Default: HomeAddress

UserInfoConst.INFO_WorkAddress

Work address

Kind: static constant of UserInfoConst
Default: WorkAddress

UserInfoConst.INFO_Citizenship

Citizenship

Kind: static constant of UserInfoConst
Default: Citizenship

UserInfoConst.INFO_GovernmentRegID

Country-specific unique registration ID, e,g, SSN, PersonalCode, etc.

Kind: static constant of UserInfoConst
Default: GovernmentRegID

UserInfoConst.INFO_AvatarURL

URL of avatar image

Kind: static constant of UserInfoConst
Default: AvatarURL

documented by jsdoc-to-markdown.
