Mast: a Math AST for Golang

Because Go does not support operator overloading, most numerical libraries are messy to use. Mast is an attempt to write a domain-specific language for math, so that code can be written in a more simple way.

If it helps, think regular expressions, but for algebra.

// with Mast
mast.Eval("x = A' * b + c", &x, &A, &b, &c)

// without Mast
Transpose(&aT, &A)
Times(&Atb, &At, &b)
Plus(&x, &Atb, &c)

Parser

Mast mostly exists to create parsers for math-like languages. To use it, first create a *mast.Parser object, configuring the various operations and their precidence.

// A Parser configures the given operators in terms of precedence.
type Parser struct {
	// Define which operators appear in this language. These operators are
	// given in order of loosest to tightest (so addition/subtraction should
	// probably come before multiplication/division).
	Operators []Prec

	// Define which matching grouping operators are used.
	Groups []Group

	// If true, then "sin x" is legal and parses as "sin(x)" would. If false,
	// that is a syntax error.
	AdjacentIsApplication bool
}

Then you invoke the (p *mast.Parser).Parse(string) (*mast.Equation, error) function.

// Parses a single equation in the given source. On success, e is a
// parsed *Equation; iff not, error is non-nil and of type Unexpected{}.
func (p Parser) Parse(source string) (e *Equation, error) {

Example

Suppose we want to make a basic calculator parser. First, define which operations and grouping operators we want to support:

integers := &mast.Parser{
	// allow parentheses
	Groups: []Group{
		{"(", ")"},
	},

	// add plus, minux, multiply, divide, and modulo
	Operators: []Prec{
		{[]string{"+", "-"}, InfixLeft},
		{[]string{"*", "/", "%"}, InfixLeft},
		{[]string{"-", "+"}, Prefix},
	},
}

To parse a string using this language, invoke (p *mast.Parser) Parse(string) (*mast.Equation, error) with the source code to evaluate. For example, if we run:

tree, err := integers.Parse("y = (-a) * b + c")
fmt.Printf("tree: %v\n", tree)

then err will be nil and tree will be as follows:

tree := &Equation{
	Left: &Var{"y"},
	Right: &Binary{
		Op: "+",
		Left: &Binary{
			Op: "*",
			Left: &Unary{
				Op: "-",
				Elem: &Var{"a"},
			},
			Right: &Var{"b"},
		}
		Right: &Var{"c"}
	}
}

By iterating over the tree, your DSL can evaluate the mathematical expression while maintaining type integrity.

Evaluator

Mast includes a toy evaluator that handles matrices as [][]float64. To use it, invoke the Eval(code string, args ...interface{}) error function, passing pointers to the respective arguments.

// Evaluate the given expression with the given variables. Variables are
// assigned left to right based on first usage.
func Eval(code string, args ...interface{}) error {

Think %-arguments to fmt.Printf. To make setting up variables easier, arguments can be specified in three ways:

• a [][]float64 for an n x m matrix;
• a []float64 for an 1 x n column vector; or
• a float64, for a 1 x 1 scalar.

All other types panic.

Example

Suppose we want to compute a linear transform (multiplying a vector by a matrix, and adding a vector). First, we set up the variables to compute:

A := [][]float64{
	[]float64{1, 2},
}

x := []float64{3, 4}
// same as := [][]float64{[]float64{5}, []float64{6}}

b := 5.0
// same as := [][]float64{[]float64{5.0}}

y := 0

Once those are set up, the computation is fairly easy.

if err := mast.Eval("y = A * x + b", &y, &A, &x, &b); err != nil {
	handleError(err)
	return
}

The result is then available in y.

License

This code is covered under the MIT license.
