Software designed for analysis of microscope imaging data
Dot Scanner is designed to simplify analysis of microscope imaging data. The program runs entirely within a window-based graphical user interface, so as to not require any programming knowledge from the user in order to complete their image analysis (see the images below for examples). This software is especially useful for noisy image data, where manual "by-eye" analysis is unreliable.
Python 3 must be installed before Dot Scanner can be installed. Python 2 is not supported. To make sure you have Python 3 installed, open a terminal window and run the following command:
python3 --version
(Note: Running this command might require installing command line developer tools. This is normal, and it is ok to install this.)
This should give version number (i.e., Python 3.x.x). If a "command not found" message is shown instead, then Python 3 is not properly installed.
To install Dot Scanner, open a terminal window and run the following command:
pip3 install dotscanner
(Note that the pip command may be required instead of pip3 for some Python 3 installations.)
To update Dot Scanner to the latest version, run the following command (again, using pip instead of pip3 for some Python 3 installations):
pip3 install dotscanner --upgrade
Dot Scanner can also be uninstalled at any time using the following command (again, using pip instead of pip3 for some Python 3 installations):
pip3 uninstall dotscanner
To launch the main graphical user interface (GUI), run the following command:
dotscanner
Note: if you are getting an error when trying to run the program, run the following command to check your Python version:
python3 --version
Python 2 is not supported, and Python 3 must be installed to run Dot Scanner.
Some demo images are included in the demo images folder of this GitHub project, which can be downloaded and used as explained below to familiarize oneself with how the software works.
The first window displayed in the GUI is the Configurations Window:
If the File or Folder buttons are clicked, another window opens, allowing the user to select a file or folder for analysis (the images in the demo images folder can be downloaded to try this out for oneself):
If repeated analysis is being performed at the same target filepath, the user can avoid continuously repeating this step by setting a default filepath. This is done by clicking the "Edit defaults" button. An entire configurations file is editable for other defaults as well. Any of the variables in this configurations file can be modified to change the default behavior of the software.
The software will run as expected on any folder where the most common file extension within the folder belongs to the images wanting to be analyzed. By default, the entire folder will be scanned, and the most common file type found within the folder will be set as the file type to analyze. If the user is experiencing issues with the wrong file type being selected, it is recommended that they reorganize their data into folders containing only their images to be analyzed.
If a folder containing several images is selected, the user has the option to change the default program from Density to Lifetime. (Note that trying to run a lifetime program on a single image will not be allowed by the software.) This selection is made through the Program dropdown menu:
If Lifetime is selected, some additional options will appear:
Selecting this option will output graphical plots to a figures folder that will be created within the folder containing the data being analyzed. These plots serve to allow the user to quickly verify their selections made during analysis.
This option sets the radius (or, more accurately, roughly the half width of a square) of exclusion around "blobs" (in pixels). Blobs are regions of the image that are saturated and overexposed. For example, if the blob size is set to 5, then a square region extending 5 pixels in each direction (left, right, up, and down) will be defined from each overexposed pixel (meaning the square will span 11 pixels on each side, including the central pixel), and all of the pixels within those regions will be ignored during analysis. This ensures that the “dots” (the dimmer particles of interest in the image) are not too close to any of these regions, and thus the outer edges of blobs are not confused as dots.
Similar to the blob size option, this sets the size of a "dot" in the dataset. Because dots should not overlap, the larger the dot size, the fewer dots will be detected, as dimmer pixels within a brighter dot's region will not be recognized as dots, and will therefore be removed.
There are three thresholds that can be set to adjust the detection sensitivity for "dots" and "blobs" in a given image. The three editable text boxes correspond to the following variables (displayed from left to right in the Configurations Window):
LOWER_DOT_THRESH_SCALE: Scaling for the lower threshold defining the brightness of the dots. The default is 1.5, which corresponds to 1.5 standard deviations above the mean of the data. Lower this value to increase the number of faint dots detected, or raise it to reduce the number.UPPER_DOT_THRESH_SCALE: Scaling for the upper threshold defining the brightness of the dots. The default is 5, which corresponds to 5 standard deviations above the mean. Lower this value to reduce the number of bright dots detected, or raise it to increase the number.LOWER_BLOB_THRESH_SCALE: Scaling for the lower threshold defining the brightness of the blobs. The default is 2, which corresponds to 2 times the value of UPPER_DOT_THRESH_SCALE. Lower this value to increase the number of blobs detected, or raise it to reduce the number.This opens a new window that allows the user to edit the default filepath or edit/reset the entire configuration file directly.
This opens a new window that allows the user to browse for a previous .txt analysis file to use to repeat analysis. Information on which settings are reused during re-analysis is included in the header of each analysis file. There are two main scenarios for using this feature:
Clicking Next, or pressing the return key on the keyboard, will save the user’s selections and open the Threshold Adjustment Window.
This option sets the first image to be considered in a lifetime calculation. The default is the first image in the folder (as the images must be numbered sequentially).
This sets the number of consecutive images that are allowed to be skipped in a lifetime calculation. This can be useful for dimmer dots where an image or two in a series are relatively out of focus, resulting in an unwanted non-detection for those frames. By increasing the number of skips allowed, these particles will be retained as long as they are back in focus and bright enough for detection in subsequent frames.
This dictates whether edge frames should be removed from a lifetime calculation. If a particle is detected in the first frame of an image, for example, it cannot be determined whether the particle existed before the first image was taken, so it might not make sense to include this in a lifetime calculation (and the same may also be true for particles in the last frame). If the number of skips allowed in the lifetime calculation is greater than zero, this will increase how many edge frames are removed from analysis.
Note: If the user is working with particularly noisy datasets where noise tends to be incorrectly marked as short-lived particles, the LIFETIME_THRESHOLD value in the configurations file can be adjusted to mark them as potentially unreliable in the output file.
Clicking the Next button, or pressing the return key on the keyboard, from the Configurations Window saves the configuration settings selected by the user and advances to the Threshold Adjustment Window. This window shows the image data with the dots and blobs identified, and features several button groups on the left sidebar:
From top to bottom, these button groups perform the following actions:
These buttons allow four different viewing options: zooming in on the top left, top right, bottom left, bottom right, or zooming back out to show the full image. The user can also press the spacebar on the keyboard to cycle through these different views.
These buttons adjust the contrast of the image.
These buttons adjust the sensitivity for detecting “dots” in the image (the fainter, smaller dots, as opposed to the much brighter and larger “blobs”). The user can also press the up and down arrow keys on the keyboard to make these adjustments.
These buttons adjust the sensitivity for detecting “blobs” in the image. The user can also press the right and left arrow keys on the keyboard to make these adjustments. Note: since increasing the blob sensitivity changes the threshold between blobs and dots, this results in a different number of dots being detected as well.
This button changes the left button bar view to display some manual threshold and size adjustment options:
(Once the thresholds or sizes are changed by entering new numbers into the text boxes, clicking the Done button, or pressing the return key on the keyboard, saves the settings and returns the left button bar to the original button configuration.)
This button resets the adjusted thresholds back to the default values.
This button skips the current image (for example, if the user decides the data quality is not sufficient for measurement). The escape key on the keyboard can also be pressed to perform a skip.
Clicking the Done button, or pressing the return key on the keyboard, from the main Threshold Adjustment Window saves the threshold settings selected by the user and advances to the Region Selector Window:
This window allows the user to click different locations on the image to set the vertices of a polygon within which the measurements will be made. At any point, the polygon can be reset by clicking the Reset button, or by pressing the backspace key on the keyboard. It is important to note that after at least three vertices have been placed, the dotted line shows how the program will enclose the polygon once the Done button, or the return key on the keyboard, is pressed. (In other words, it is not necessary to re-click the first vertex created to close the polygon.)
Information about the image processing will be displayed in the terminal, including progress bars to estimate the time to completion of longer processes, like lifetime calculations and the saving of multiple figures.
Note: the extraneous +[CATransaction synchronize] output in the terminal window is a known bug in macOS that will not affect your data.
Holly Allen (holly.allen@colorado.edu)
Brian Davis
This project is licensed under the MIT License. See the LICENSE file for details.
To contribute, download or clone the project. From the top level of the project's folder structure, one can use the following command to run a local version of the software (e.g., for UI testing):
python -m dotscanner
(Note that the python3 command may be required instead of python for some Python installations.)
Unit tests for this software were written for use with Python's built-in unittest framework, and are stored in the tests folder. To run tests, download the project, navigate to the top level of the project's folder structure and run the following command:
python -m unittest
(Note that the python3 command may be required instead of python for some Python installations.)
To report a bug, visit the issues page. New feature requests are also welcome!
When using this program on data used in published works, please cite:
Allen, H., Davis, B., Patel, J., & Gu, Y. 2024 (in prep.)
